ATEX Approved Emergency Light Exit Signs Explosion Proof Emergency
Light
What are explosion proof lights?
Explosion proof lights are high resistance light which can work in
harsh condition zones such as railways, coal mines, factories,
manufacturing sites,and other similar areas. Most explosion proof
lighting is being manufactured using LED technology by top LED
manufacturers. This is happening because LED lights are more energy
saving & eco-friendly as compared to other bulbs.
The deference between Anti proof lamp and general lamp: For
explosion proof light, its features: waterproof,dust proof, prevent
fire gas entering, there is anti explosion mark on the lamp housing
cover.
Product Features:
Shell compact structure,high density material
strength,Explosion-proof performance,the surface of plastic power
adhesion ability with good anti-corrosion.The surface
smooth,elegant appearance;
Built in normal condition and auto-lighting while accident happened
or power tic ally in normal condition and auto-lighting while
accident happened or power is failure conditions.
Inducing signals can be selected by users.
LED lighting diode,is in low consumption,the life can be up to 1000
hours long emergency time and it is no maintenance.
Product Description
1. Can be used in hazardous areas: Zone 1 and Zone 2 .
2. Can be used in explosive gas atmospheres of Category IIA, II B
and II C where the temperature classification is T1-T6.
3. Hazardous zone : 20. 21. and 22
4. Flammable dust atmosphere.
5. widely used in the fields of oil, chemical industry ,
spaceflight ,war industry and so on.
Techinical Parameters:
Meet a criterion:G3B3836.1, GB3836.2, GB12476.1,
IEC60079-0,IEC60079-1, IEC61241-1, EN60079-0, EN60079-1, EN61241-1
Ex---proof Mark:Exd II BT6 Gb, Exd II CT6 Gb, DIP A21 TA, T6.
Rated voltage: AC220V
Ligting Source: Plz Refer the Selection Table.
Protection grade:IP65
Corrosion-proof grade:WF1,WF2
Inlet Thread: G3/4"
Cable outer dia:9mm~14mm
Installation Process
Applications:
Suitable for explosive gas environment Zone1 and Zone2.
Suitable for IIA,IIB,IIC explosive gas environment.
Suitable for Hazarous dust area: Zone20, Zone21, Zone22.
Can be used in the environment of temperature group for T1~T6.
Lighint source: LED.
Mainly used for exit signs and direction in emergency conditions.
Designed for petroleum explosion, refinery, storage, chemistry,
medicine, military etc. sites with potential explosive atmosphere.
Product Specification
| Product Name | Exit Signs Explosion Proof Emergency Light |
| Power Consumption | 5W |
| Input Voltage | Applied for 85-265V |
| Frequency | 50/60Hz(applied for 47-63 Hz) |
| Beam Angle | 45°/60°/90°/120°/140° |
| Explosion-proof Grade | Ex dIIB T6 |
| Corrosion-proof Grade | WF1 |
| Color Temperature(K) | Warm white:2700-4000K; Pure white:5000-6500K |
| Power Factor | >0.95 |
| Light Efficiency | >100lm/w |
| Ambient Temperature | -55°C~+60°C |
| Lifespan | >50000Hrs |
| Emergency start | 0.3s |
| Material | Aluminium Alloy |
| Dimensions | 270*210*85mm |
| Net weight | 2KG |
Company Introduction
Chengdu HKV Electronic Technology Co.,Ltd., established in 2016. We
are located in Chengdu City of Sichuan Province. We are
professional on R&D, manufacture and offer quality outdoor &
industrial LED lighting. HKV committed to provide professional
solutions and technical service to customers. Our main R&D
engineers have more than 10 years experience in the Led lighting.
HKV strictly complies with ISO-9001 and the workshop is managed
according to the 7S site management system.
HKV takes quality as superiority and offer excellent pre-sale
support and after-sale services. HKV not only provides customers
with the high quality products with competitive price, but also
offers the corresponding solutions.
Mission: Not just LED manufacturer, but one professional LED
solution provider.
