NEW-FBP-200W high power explosion proof led fixture high bay light
for industrial area
1. Details of 200W
| Model Name | NEW-FBP-200W |
| Input voltage | AC90-265V |
| Power frequency | 50/60Hz |
| Power factor | 0.96 |
| Watte | 200W |
| Lumen | 22000lm |
| Luminous Efficiency | 110-130lm/w |
| CCT | 2700-3500K 3500-5000K 5000-6500K |
| CRI | Ra>=85 |
| Operating Temperature | -30℃ to 45℃ |
| IP | IP66 |
| Anti-corrosion | WF2 |
| Lifespan | >50000h |
| Certification | EX, IECEx, ATEX, CE, WF2 |
| Explosion Grape | II 2G Ex db eb mb IIC T4~T6 Gb IP66
II 2D Ex tb, IIIC T95℃ Db
Zone1, Zone2
Zone 21, Zone 22 |
2. The professional explosion proof light
- Energy saving & Lower power consumption & Environment friendly;
- Invention patented technology registered at overseas & domestic:
A. Heat dissipation design zmwm02
B. Flexible light distribution solution.
- Light efficiency of whole lamp reaches over 95lm/W; Color rendering
index is over 80Ra; Exact color temperature control, no deviation.
- High quality power supply from MOSO brand (Chinese listed company
):
A. Single Channel and Constant Current Design;
B. Universal AC input(90-305Vac);
C. Ultra-wide constant current region for output;
D. High efficiency;
E. Multi-Protection: Short Circuit, Over-load, Over-voltage, and
Lightning Protection etc.
- High protection grade: IP67, good enough to against moist and dust.
Lamp is deeply electrophoresed and then anti-corrosion painted to
maintain a long time good surface performance, salty corrosion
resistance.
- Smaller package size: Save freight by 30%
3. Fence or Flange assembles
4. Package details
N.W.: 8.2kg
Inner carton size: 39*39*28cm
Outer carton size: 40*40*28 (1pcs/ctn)
G.W.: 10kg/ctn
5. Company goal
HKV takes quality as superiority and offer excellent pre-sale
support and after-sale services. HKV not only provides customers
with the high quality products with competitive price, but also
offers the corresponding solutions.
Mission: Not just LED manufacturer, but one professional LED
solution provider.
6. HKV-FAQ
Q: How to order our product ?
A:1). Please tell us the model and quantity and other request you
need.
2). We make the PI for you.
3). After you confirm the PI, we arrange the order for you after
receiving your payment.
4). After the goods finished, we send the goods out to you and tell
you the tracking number.
5). We will track your goods until you receive the goods.
Q: What's your warranty ?
A: Two years
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we
checked and compare, then provide customer the most proper shipment
method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept
?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by Maoyt or send us by email,
we will reply within 24hrs.
